SMC core for electronic water pump
FRING’s SMC cores for electronic water pumps utilize soft magnetic composite technology to achieve 3D isotropic magnetic properties. These cores reduce eddy current losses and enable compact motor designs, delivering high efficiency and thermal stability for EV and hybrid thermal management systems.
Main Datasheet
Applicable Specifications
Stringent Standards, Precision Specifications, Ultimate Reliability
Design & Quality Standards
ISO 9001, IATF 16949, RoHS
Standard Material Grades
FR-SMC-500, FR-SMC-600 (customizable)
Typical Magnetic Properties
Saturation Flux Density ≥1.6 T Permeability (max) ≥500 Coercivity ≤250 A/m
Typical Physical Properties
Density 7.3 – 7.5 g/cm³ Core Loss ≤15 W/kg @ 1000 Hz, 1.0 T Electrical Resistivity ≥100 µΩ·m
Net-Shape Dimensional Tolerances
OD/ID: ±0.05 mm Height: ±0.05 mm Flatness: ≤0.05 mm
Get Your Quote Now
MOQ: 500–2000 pcs (Negotiable depending on part design and volume)
Lead Time: 2–3 weeks for standard parts, 3–5 weeks for custom parts
OEM/ODM: Available
Engineering Support: Yes (Drawing review + Material selection + Magnetic/Mechanical parameter optimization)
