VVT (Variable Valve Timing) Stator for Automotive Engines
FRING’s Variable Valve Timing (VVT) stators are precision powder metallurgy components that control oil flow to advance or retard camshaft timing. With complex internal oil passages and tight vane slot tolerances, these stators enable fast phaser response and improved engine efficiency and emissions.
Main Datasheet
Applicable Specifications
Stringent Standards, Precision Specifications, Ultimate Reliability
Design & Quality Standards
IATF 16949, ISO 9001, SAE J1855
Standard Material Grades
MPIF: FL-4605, FC-0208
Typical Material Properties (Sintered Fe-Cu-Ni-Mo)
Density 6.8 – 7.2 g/cm³ Hardness 25 – 35 HRC Tensile Strength ≥450 MPa
Net-Shape Dimensional Tolerances
Vane Slot Width: ±0.01 mm Oil Passage Position: ±0.10 mm Flatness: ≤0.05 mm
Performance Verification
Leakage Rate ≤5 ml/min @ 5 bar Phaser Response Time ≤100 ms
Get Your Quote Now
MOQ: 500–2000 pcs (Negotiable depending on part design and volume)
Lead Time: 2–3 weeks for standard parts, 3–5 weeks for custom parts
OEM/ODM: Available
Engineering Support: Yes (Drawing review + Material selection + Magnetic/Mechanical parameter optimization)
